General
Lens Material - chemically strengthened glass
Dimension 2.65" x 7" x 1.7" (6.75w x 17.8h x 4.4d cm)
Weight - 9.59 oz (272 g)
Water rating - IPX7
MIL-STD-810 yes (thermal, shock, water)
Display Type - transflective, 65K color TFT
Display Size - 1.5"W x 2.5"H (3.8 x 6.3 cm); 3" diag (7.6 cm)
Display Resolution - 240 x 400 pixels
Battery type - re - rechargeable, internal lithium-ion
Battery life up to 35 hours at 10-minute tracking; up to 200 hours at 30-minute tracking (power save mode)
Memory/History16 GB (user space varies based on included mapping)
Interface - high speed microUSB and NMEA 0183 compatible
Maps & Memory
Ability to add maps - Basemap
Map segments - 15000
Satellite Imagery - yes (direct to device)
Includes searchable points of interests (parks, campgrounds, scenic lookouts and picnic sites) Yes (downloadable from Garmin Express™)
Displays national, state and local parks, forests, and wilderness areasYes (downloadable from Garmin Express™)
External memory storage - yes (32 GB max microSD™ card, not included)
Waypoints/favorites/locations - 10000Tracks
250 Navigation Track Log
20,000 points, 250 saved gpx tracks, 300 saved fit activities
Navigation Routes - 250, 250 points per route; 50 points auto routing
Rinex logging
Sensors
GPSGalileoBarometric altimeterCompassYes (tilt-compensated 3-axis)High-sensitivity receiverGPS compass (while moving)
Daily Smart Features
Connect IQ™ (downloadable watch faces, data fields and apps)Smart notifications on handheld
Weather forecastsWeather (removing Active)
Compatible with Garmin Messenger appVIRB® RemotePairs with Garmin Connect™ Mobile
Safety and Tracking Features
LiveTrack
Tactical Features
XERO™ Locations
Outdoor Recreation
Point-to-point navigation
Area calculation
FISH FORECAST
Sun and moon information
Geocaching-friendly - Yes (Geocache Live)
Custom maps compatible - Yes (500 custom map tiles)
Picture viewer
LED beacon flashlight
inReach® Features
Interactive SOS
Weather (removing InReach)
Send and receive text messages to SMS and email
Send and receive text messages to other inReach device
Send and receive group messages
Exchange locations with other inReach device
MapShare compatible with tracking
Virtual keyboard for custom messaging
Send waypoints to MapShare during trip
Send route selection to MapShare during trip
inReach remote compatible
Outdoor Applications
Compatible with Garmin Explore™ app
Garmin Explore website compatible
Connections
Connections Wireless Connectivity
Wi-Fi®, Bluetooth®, ANT+®
