Motorola MOTOTRBO SLR 1000 Repeater

Compact DMR Repeater Coverage for Challenging Locations

Need to extend radio coverage without installing a large repeater system?

The Motorola MOTOTRBO SLR 1000 Repeater is designed to deliver reliable radio communications in places where traditional repeaters are difficult, expensive, or impractical to install.

Its compact design, IP65 protection, and low-power operation make it ideal for expanding coverage across sites, buildings, tunnels, workshops, campuses, quarries, industrial facilities, and remote locations.

Key Features

• MOTOTRBO digital and analogue repeater
• Available in VHF and UHF models
• IP65 dust and water protection
• Compact wall or pole mount design
• Fanless operation
• Low power consumption
• Supports voice and data communications
• Compatible with MOTOTRBO conventional and trunked systems
• Supports IP Site Connect
• Supports Capacity Plus
• Supports Capacity Max
• Extended Range Direct Mode support
• Up to 64 channels
• Weather-protected connectors
• Indoor and outdoor installation options

Expand Radio Coverage Without Major Infrastructure Costs

Dead spots create communication problems.

Missed calls.

Safety risks.

Operational delays.

The SLR 1000 helps extend radio coverage into areas where signal strength is poor or unreliable.

Whether your team works across multiple buildings, large industrial sites, forestry operations, transport yards, tunnels, underground access points, or remote work areas, the SLR 1000 helps keep communications flowing.

Designed for Indoor and Outdoor Deployment

Many repeaters require controlled environments and dedicated equipment rooms.

The Motorola SLR 1000 takes a different approach.

Its IP65-rated enclosure protects against dust and water ingress, allowing installation in demanding environments where standard infrastructure may not be suitable.

Ideal deployment locations include:

• Quarries
• Forestry operations
• Mining sites
• Ports
• Warehouses
• Manufacturing plants
• Transport depots
• Car parks
• Campuses
• Remote communication sites

Reliable coverage starts with flexible deployment.

Compact Size Creates More Installation Options

Finding space for radio infrastructure can be difficult.

The compact footprint allows installation where larger repeaters simply will not fit.

The unit can be:

• Wall mounted
• Pole mounted
• Installed in cabinets
• Deployed at remote communication sites

More installation flexibility often means lower project costs.

Fanless Design Means Lower Maintenance

Moving parts eventually fail.

The SLR 1000 uses a fanless design that reduces:

• Noise
• Dust ingress
• Maintenance requirements
• Power consumption

Fewer components can mean greater long-term reliability.

Grow Your Radio Network Over Time

Many businesses start with a simple radio system and expand later.

The SLR 1000 supports:

• Analogue conventional systems
• Digital conventional systems
• IP Site Connect
• Capacity Plus
• Capacity Plus Multi-Site
• Capacity Max trunking systems

This allows the repeater to remain part of your network as your communications requirements evolve.

Extended Range Direct Mode

For conventional MOTOTRBO systems, the SLR 1000 supports Extended Range Direct Mode.

This allows radios to communicate through the repeater while operating on a single frequency pair, helping extend coverage without requiring additional frequencies in some applications.

Ideal Industries

The Motorola SLR 1000 is well suited for:

• Forestry
• Mining
• Civil construction
• Manufacturing
• Warehousing
• Transport and logistics
• Ports
• Utilities
• Security operations
• Tourism operators
• Education campuses
• Local government infrastructure

Where communication coverage matters, the SLR 1000 delivers practical results.

Technical Specifications

• Frequency Bands:
  • VHF 136–174 MHz
  • UHF 400–527 MHz
• RF Output Power:
  • 1–10 Watts
• Channel Capacity:
  • 64 Channels
• Channel Spacing:
  • 12.5 / 20 / 25 kHz
• Protection Rating:
  • IP65
• Dimensions:
  • 279.4 × 228.6 × 101.6 mm
• Weight:
  • 4.54 kg
• Operating Temperature:
  • -30°C to +60°C
• Modes:
  • Analogue
  • Digital
  • Half Duplex
  • Duplex
• Connectivity:
  • Ethernet
  • AUX Port
  • DC Power Input

Why Choose the Motorola SLR 1000?

Not every site needs a large, high-power repeater.

Sometimes the challenge is simply getting reliable coverage into difficult areas.

The Motorola SLR 1000 provides a professional-grade solution that is compact, rugged, scalable, and cost-effective.

For organisations wanting dependable MOTOTRBO coverage extension without major infrastructure requirements, the SLR 1000 is one of the most flexible repeater platforms available.

Frequently Asked Questions

Is the Motorola SLR 1000 suitable for outdoor installation?

Yes. The repeater carries an IP65 rating and is designed for both indoor and outdoor deployment.

Does the SLR 1000 support digital radio systems?

Yes. It supports MOTOTRBO digital systems as well as analogue radio networks.

Can the SLR 1000 be used with Capacity Plus or Capacity Max?

Yes. The repeater supports both Capacity Plus and Capacity Max system architectures.

What output power does the SLR 1000 provide?

The repeater supports adjustable output power from 1 to 10 Watts.

Is the SLR 1000 suitable for forestry and quarry operations?

Yes. Its compact size, environmental protection rating, and flexible installation options make it well suited to forestry, quarry, mining, and industrial applications.
