Icom IP1100CV Wi-Fi Radio Controller, up to 300 Radios

System controller for up to 300 IP110H Wi-Fi radios

Recommended for new systems: the IP1100CV is the controller we recommend for new IP110H Wi-Fi radio systems. The Icom BC-207S AC power adaptor is sold separately.

Overview

Every Icom Wi-Fi radio system needs a controller, and the IP1100CV is Icom's current one. It sits on your network, registers every radio, and routes individual, group and all-call traffic through your Wi-Fi access points.

It handles up to 300 radios, three times the capacity of the older IP1000C, and links sites together over a secure VPN. New to Wi-Fi radio? Start with our Icom IP Advanced Radio System overview.

Key Features

• Up to 300 radios registered, including IP100FS dispatch PCs, means one controller can cover a large site, for shopping centres, distribution centres and multi-building campuses.
• Auto-provisioning means new radios pick up their settings as soon as they join the network, for IT teams rolling out or replacing radios.
• Up to 500 call addresses means individual and group calls can be set up to match how your teams actually work, for operations with many departments.
• 2.5 Gbps WAN port with VPN router function means sites can be linked securely over the internet, for multi-site operators.
• Web browser programming and online firmware updates means the system is managed from a PC, without special software or site visits, for site and IT managers.
• Audio recording to a USB flash drive means specified calls can be kept for review, for incident follow-up and training.
• Settings export and import by USB means a quick backup and restore, for anyone maintaining the system long term.
• 1U half-width, rack-mountable design with a security slot means it fits neatly into a 19-inch comms cabinet, for sites with a server room.

Applications

• Shopping centres and retail operators
• Warehouses and distribution centres
• Tunnelling and underground construction
• Factories, hospitals and hotels running Wi-Fi radio fleets

What's in the Box

• IP1100CV controller
• Magnet legs
• Screws
• Clamp
• Flat washer and screw

The AC power adaptor (Icom BC-207S) is not included and must be ordered separately. The MBF-6 19-inch rack mount bracket is optional.

Compatible With

• Icom IP110H Wi-Fi radio
• Icom IP100H Wi-Fi radio (existing fleets)
• Icom IP100FS PC dispatch software
• Icom VE-PG4 RoIP gateway (for VPN linking and connecting to other radio systems)
• Icom AP-95M and third-party Wi-Fi access points, including Ubiquiti

Complete Your Setup

A working system needs the controller, IP110H radios, the BC-207S power adaptor and Wi-Fi coverage across your site. Not sure what your network needs? See the full IP Advanced Radio System page or talk to us and we'll check your access points before you buy.

Key Specifications

FAQs

Does the IP1100CV come with a power supply?
The IP1100CV does not come with a power supply. The Icom BC-207S AC adaptor is ordered separately, and we can supply it with your controller.

How many radios can the IP1100CV run?
The IP1100CV can register up to 300 Wi-Fi radios, including IP100FS dispatch PCs, with up to 500 call addresses for individual and group calls.

Will it run my existing IP100H radios?
Yes, the IP1100CV runs both IP110H and IP100H radios, so existing IP100H fleets can move onto it and add new IP110H radios over time.

Do I need a radio licence?
You don't need an individual radio licence. The system runs over standard Wi-Fi frequencies on your own network, with no annual licence fee or call charges.

Can I use my existing access points?
In many cases you can use your existing access points. The system works with third-party access points, including Ubiquiti, as well as Icom's AP-95M. We'll check your coverage before you commit.

Can it link more than one site?
It can link multiple sites over a secure VPN, either to another IP1100CV or to a VE-PG4 gateway, so staff at different sites talk as if they were in one building.
